Transmission Flange

Description：High-performance forged transmission output flange for heavy-duty trucks and construction vehicles. Compatible with FAST, ZF, EATON gearboxes. Offers excellent torsional strength, anti-corrosion finish, and OEM fit. Custom bolt patterns and spline types available for various transmission systems.

Product model：

Category ：Transmission System

Update time：2025-06-26

Product introduction:

The gearbox flange (also called output flange/drive flange head) is an important component connecting the transmission and the drive shaft. It is mainly used to efficiently transmit the torque output of the transmission to the drive shaft to achieve stable output of the power system. The product is made of high-strength alloy steel or forged material, with strong torsion resistance, high coaxiality, precise installation and other characteristics. It is widely used in heavy trucks such as HOWO, Dongfeng, Shaanxi Automobile, Foton, Jiefang, and engineering machinery equipment.

Technical Specifications:

Parameter	Specification
Material	Forged alloy steel / 45# steel / Ductile iron (QT500)
Compatible Gearboxes	FAST, ZF, EATON, HW19710 / HW18709, etc.
Surface Treatment	Black phosphate / Electrophoretic coating / Zinc plating
Connection Type	Bolt holes / Spline / Flanged
Outer Diameter Range	90mm – 220mm (varies by model)
Center Hole / Spline Type	Customizable according to drawings or OEM standards
Application	Heavy trucks, construction machinery, transmission assemblies
