Brake Chamber for Air Brake System

Description：High-quality brake chamber for air brake systems in trucks and trailers. Available in Type 24, 30, and 24/30. Durable steel construction, high-pressure performance, and OEM compatibility.

Product model：

Category ：Brake System

Update time：2025-06-24

Product Introduction

The brake chamber, also known as a brake actuator or air brake chamber, is a critical component of an air brake system in heavy-duty trucks, trailers, and buses. It converts air pressure from the brake system into mechanical force to apply the brakes. This product includes both service brake chambers and spring brake (emergency/parking) chambers, available in types such as Type 24, Type 30, and Type 24/30 combo.

Manufactured with high-strength steel housings, corrosion-resistant diaphragms, and reliable push rods, our brake chambers ensure safe, responsive, and long-lasting braking performance.

Key Features

Durable steel housing with anti-corrosion coating

High-strength spring and reinforced diaphragm for long service life

Available in multiple types: Type 16, 20, 24, 30, 24/30, etc.

Compatible with various truck brands: HOWO, FAW, Dongfeng, Freightliner, Volvo, etc.

100% air leak tested before delivery

Easy to install and fully interchangeable with OEM parts

Technical Specifications:

Parameter	Specification
Product Type	Brake Chamber / Spring Brake Actuator
Available Sizes	Type 16 / 20 / 24 / 30 / 24-30 Combo
Application	Air brake systems for heavy trucks/trailers
Operating Pressure	0.6 – 0.8 MPa
Push Rod Length	Standard / Customizable
Stroke	64mm / 76mm (varies by model)
Material	Steel shell with powder-coated finish
Certification	ISO/TS16949, DOT, CE (optional)
OEM/ODM Support	Available
